TCIB04/06 Features

TCIB04/06 is a multiple-channel non-inverting 3-state buffer in different packages. QFN20/TSSOP20 packages are for 6-channel buffer and TSSOP14 for 4-channel buffer.
All the channels can work independently, which means each channel has the dedicated control pin to turn on or off the buffer separately. Both OEn and An input signals are with Schmitt trigger. Output Yn is high impedance when OEn is low.

AEC-Q100 Grade 1 Qualified and PPAP Capable

Wide power supply range: 1.65V~5.5V

Sink/Source current up to 16mA at 5V

Rising/Falling Time: Typical 1.1ns/0.7ns with 10pF Cload

Rising/Falling Delay Time: Typ. 2.9ns/2.1ns w/ 10pF Cload

Schmitt-trigger inputs allow for slow or noisy input signals

Low power consumption

Typical supply current IVCC 0.5uA
Typical input leakage current IIL < 0.1uA

Operating temperature TA: -40~125°C

Packages：

TSSOP-14
QFN-20
TSSOP-20

ESD：±2KV（HBM）/ ±2KV（CDM）
